| Item | Fiber Optical Modules |
| Vendor Name | Specialized Manufacturer |
| Part Status | Active |
| Form Factor | QSFP |
| Max Data Rate | 103.125Gbps (4x 25.78Gbps) |
| Max Cable Distance | 70m@OM3 / 100m@OM4 |
| Wavelength | 850nm |
| Connector | MTP/MPO-12 |
| Commercial Temperature Range | 0 to 70°C (32 to 158°F) |
| Transmitter Type | VCSEL 850nm |
| TX Power | -8.4 ~ 2.4dBm |
| Receiver Sensitivity | < -10.3dBm |
| Power Budget | 1.9dB |
| Receiver Overload | 2.4dBm |
| Power Consumption | ≤ 2.5W |
| Extinction Ratio | > 3dB |
| DDM/DOM | Supported |
| Warranty | 5 Years |
| Sample | Available |
| Protocols | IEEE 802.3bm, QSFP28 MSA, SFF-8665, SFF-8636, RoHS, CPRI, eCPRI |
As a specialized manufacturer of magnetic telecom and networking components, we are certificated by ISO9001:2000, ROSH, REACH, CE and UL. Our facilities own advanced manufacturing equipment and test instruments imported from abroad.
Established in 1997, we currently have around 2000 staff members. With an abundant productive capacity of 3000K per month, we are able to deliver products within a short lead time.
Our expertise extends to a full series of optical modules for fixed access, wireless access, carrier Ethernet, WDM, and data communication networks. We develop, manufacture, and sell high-speed optical interconnection solutions globally, utilizing the latest optoelectronics technologies.
